DC Water Pump

The F33 12V/24VDC self-priming diaphragm water pressure booster pump offers customizable options, delivering reliable self-priming performance and stable water pressure for industrial, agricultural, and commercial applications.

The 115V or 230V AC F33-Series is our general-duty on-demand positive displacement pump.It provides reliable performance in high water flow, moderate pressure applications. This 3-chamber diaphragm pump provides up 2.0 to 4.0 gallons per minute and is capable of self-priming up to 6 vertical feet, and can run dry without damage.

The F42 DC 12V or 24V Booster pump is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. Designed by 4 stronger chambers, the pump could provides up flow from 2.0 to 5.5 GPM and is capable of self-priming up to 6 vertical feet, and can run dry without damage. Serves 3 or more 1/2” (13 mm) outlets.This automatic demand water system pump has a built-in pressure switch, which automatically starts and stops when the faucet is opened and closed. They're easy to install, service and winterize.

The F42 Series  4 Chamber Water System Pressure Diaphragm Pump  55PSI AC 115V or 230V Booster pump is our general-duty on-demand positive displacement pump. It provides reliable performance in high water flow, moderate pressure applications. Designed by 4 stronger chambers, the water system pump could provides up flow from 3.0 to 5.5 GPM and is capable of self-priming up to 6 vertical feet, and can run dry without damage. Serves 3 or more 1/2” (13 mm) outlets.

The High flow rate  5 Chamber diaphragm pump with special design for the high flow and pressure it can be using for Yacht, RV, Caravan pressuized water ssytem, Sprayer, clean machine, water purification and other water suppply area. The pump could provide the flow from 3.0 to 5.5GPM with adjustable pressure from 15 to 70Psi.

F71 Series RV macerator pump unit is the ideal waste emptying holding tank for black and grey water solution for RV. With the Quick-Connect RV fitting, this pump easily attaches and removes in seconds. Self priming to 5ft this pump will empty a typical 30 gallon (115 Liter) holding tank in less than 3 minutes.It is the perfect choice for the waster water on RV.

The DP-35 and DP-50 series DC diaphrgm water pump build with 4 small chamber diaphragm, the pump supply the low pressure with high flow 9.5lpm, 12Lpm and 16Lpm.Option by 12V or 24V,it can be using for Motorhome, Car Washing,Garden Watering, spraying for farm chemical, House Cleaning,Boat,Caravan,etc

DDP series diaphragm pump adopts 12V Or 24V permanent DC electric machine, Customers are forbidden to use 220V power supply. If directly plug into 220V power supply. the electric machine will burn at once. If customers haven't systemic transformer equipment,you can purchase the applicable transformer in order to make the diaphragm pump operate normally.
